Double click on automatic cold heading machine
Source：http://mmjiao.cn Author：冷鐓機 Time：2014/8/17 Click：
Double click automatic cold heading machine is a specialized machine tool that uses cold heading method to manufacture various standard parts blanks such as screws and rivets. It is formed in the form of a whole mold and is suitable for manufacturers in the industry who produce screws and rivets in batches. The entire structure of this machine is automatically carried out from straightening, material selection, cutting and secondary forming to material dropping, with advantages such as stable forming standards and a wide variety of processing varieties.
型號
|
制件直徑
|
制件長度
|
主滑塊行程
|
電機（kw）
|
生產率（Pec/min）
|
外形尺寸
|
重量
|
Z12-4
|
2-4
|
5-50
|
90
|
3/6
|
85
|
1225x800x1050
|
1500
|
Z12-6
|
4-6
|
8-80
|
120
|
5.5/6
|
80
|
2350x1400x1350
|
3500
|
Z12-6A
|
4-6
|
15-130
|
180
|
5.5/8
|
55
|
2700x1500x1450
|
4000
|
Z12-8
|
6-8
|
15-130
|
180
|
7.5/6
|
65
|
3300x1600x1450
|
5500
|
Z12-10
|
8-10
|
20-150
|
200
|
11/6
|
60
|
3520x1900x1700
|
6500
|
Z12-10L
|
8-10
|
30-200
|
260
|
11/8
|
55
|
4000x2000x1800
|
8500
|
Z12-10LL
|
8-10
|
45-250
|
330
|
11/8
|
45
|
4500x2100x1880
|
10000
|
Z12-12
|
10-12
|
15-150
|
200
|
22/8
|
55
|
5500x2350x1750
|
11500
|
Z12-12L
|
10-12
|
30-200
|
280
|
22/8
|
50
|
5900x2350x1750
|
12500
|
Z12-12LL
|
10-12
|
50-250
|
330
|
22/8
|
40
|
6300x2400x1800
|
14000
|
